Model No.: KV110
Konger KS 360H Injection Molding Machine product details shows below:
|Konger Series High Speed Machinery Specifications||KS 360H|
|Injection Unit||Screw Diameter||mm||45|
|Screw L/D Ratio||L/D||23.4|
|Clamping Unit||Clamping force||KN||3600|
|Space Between Tie-Bars(WxH)||mm||655x655|
|Max. Mold Height||mm||680|
|Min. Mold Height||mm||250|
|Tie Bar Hei||mm||2000|
|Others||Max. Pump Pressure||Mpa||16|
|Oil Tank Capacity||L||620|
We design and production high speed Injection Moulding Machine for thin wall products with different production requirements, Clamping force from 1400 to 3600T,,injection weight from 106 to 311g , suitable for various plastic materials.
1.High rigidity design enables the locking minimal deformation, achieve high-speed high-voltage requirement
which will help extend the life of the die, significantly improve product accuracy.
2.The hydraulic system is equipped with an optimized injection speed greatly improved.
3.Injection components using linear guide rail, injection speed and smooth. Dedicated fast screw.
4.Special design. Showing a higher plasticizing capacity.
Contact us if you need more details on Optical Frame Injection Molding Machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Plastic Products Injection Molding Machine、High Response Servo System. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : High Speed Injection Molding Machine
