Servo System Plastic Injection Molding Machine(KS460)
Basic Info
Model No.: KS460
Product Description
| Konger Series Injection Molding Machinery Specifications | KS460 | ||||
| A | B | C | |||
| The Injection Unit | Screw Diameter | mm | 70 | 75 | 80 |
| Screw L/D Ratio | L/D | 22 | 20.5 | 19.2 | |
| Shot Volume | cm3 | 1500 | 1723 | 1960 | |
| Injection Weight(PS) | g | 1365 | 1567 | 1784 | |
| Injection Rate | cm3/s | 344 | 395 | 449 | |
| Injection Pressure | Mpa | 199 | 173 | 152 | |
| Screw Speed | rpm | 160 | |||
| The Clamping Unit | Clamping force | KN | 4600 | ||
| Toggle Stroke | mm | 740 | |||
| Space Between Tie-Bars(WxH) | mm | 770x770 | |||
| Max. Mold Height | mm | 780 | |||
| Min. Mold Height | mm | 250 | |||
| Ejector Stroke | mm | 200 | |||
| Ejector Tonnage | KN | 110 | |||
| The Others Specification | Max. Pump Pressure | Mpa | 16 | ||
| Motor Power | KW | 45 | |||
| Heater Power | KW | 30.7 | |||
| Machine Dimension | m | 7.98x1.90x2.30 | |||
| Oil Tank Capacity | L | 720 | |||
| Machine Weight | ton | 16 | |||
We are professional plastic Injection Molding Machine manufacturer for all kinds of production requirements, Clamping force from 110 to 1600T, injection weight from 140 to 10000g. With best price/ performance ration of any machine on the market.
Contact us if you need more details on Plastic Food Carton Making Machine. We are ready to answer your questions on packaging, logistics, certification or any other aspects about Normal Mould Injection Machine、Plastic Basket Making Injection molding machine. If these products fail to match your need, please contact us and we would like to provide relevant information.
Product Categories : Standard/Normal Plastic Injection Molding Machines > Servo Plastic Injection Molding Machines
